The front elevation view of the terrace pergola is given in this AutoCAD file. Download now.


Description

The front elevation view of the terrace pergola is given in this AutoCAD file. The total height of the pergola is 3.6m. The roof plan is given in this drawing. 4x8 "laminated wood beam, durock skirt, 1 x 1" @ 1 "wood fascia, 2" wood railing, and other details are given. For more details download the AutoCAD drawing file. Thank you for downloading the AutoCAD drawing file and other CAD program files from our website.
