Museum Site Design DWG with Terraces Ramps and 156425m2 Layout

This Museum Site Design DWG presents a comprehensive architectural layout covering 156,425.13 m2, showing a fully organized cultural complex with detailed terracerías drawn at escala 1 1000. The plan highlights two main terraces located at curva 81 and curva 85, connected through a circulation ramp designed with a pendiente de 5 por ciento for smooth movement across different site levels. Vertical movement is supported by two pozos de circulación vertical, each with a 4m profundidad, placed strategically to enhance access. The layout also includes a series of plazas such as Plaza de Acceso, Plaza de Esculturas, and Plaza Expo, along with clear access routes for camiones, autobuses, empleados, proveedores, and vehículos. These elements work together to create an efficient and well-structured site plan.

Additional functional zones include restaurante, cocina, bar, tienda, museografia, talleres, oficinas, mantenimiento, seguridad, casilleros, baños, and storage areas, arranged around the main circulation axis. The drawing also marks designated estacionamientos for vehículos, autobuses, reservas, and servicios especiales, ensuring organized site logistics. The combination of terraces, plazas, ramps, access points, and interior service zones makes this DWG an ideal resource for architects, civil engineers, and designers seeking an accurate and complete large-scale cultural project layout.
