Elevated Tank Drawing Free Download DWG File


The elevated steel water tank, a four-column (or four-leg) design is the most cost-effective option in most circumstances. The tank consists of a welded steel container supported by multiple welded steel legs, perimeter columns, and a welded steel center riser. These are reinforced with horizontal struts and diagonal rebar.

File Type: Autocad File ID: 185745
