A section view of the 1400x1400mm footing of base plate
Ratings & Reviews
⭐
No Reviews Yet
Be the first to share your experience with this product. Your review helps others make better decisions!
★★★★★
Description
A section view of the 1400x1400mm footing of base plate is given in this AutoCAD model. The dimension of the base plate is 200x300x10mm. 4 number of anchor bolts are used. M20 bolt size is used for this column base plate. For more details download the AutoCAD files for free from our website.
