The back side section view of the anchor bolt and flange connection details
Ratings & Reviews
⭐
No Reviews Yet
Be the first to share your experience with this product. Your review helps others make better decisions!
★★★★★
Description
The back side section view of the anchor bolt and flange connection details are given in this AutoCAD. 25mm joint is provided. M20 bolts are used. 100x100x10mm channel section is provided. For more details download the AutoCAD files for free from our website.
Tags
#The back side section view of the anchor bolt and flange connection details#Anchor bolt and flange connection details#246x245m industrial plan#AutoCAD file#AutoCAD 2D drawing file#AutoCAD model
