Building Staircase Section with Beam Slab and Foundation Layout

This AutoCAD DWG file provides a detailed building drawing prepared for structural planning and construction understanding. The drawing includes Column Details Drawing, clearly showing column positions aligned throughout the structure to support vertical load transfer and grid coordination. Column locations are placed in relation to walls and internal spaces to maintain structural balance. The drawing also represents Beam and Lintel, where horizontal members are shown above openings and across floor levels, explaining load distribution between columns and wall sections. Wall thicknesses, alignment lines, and reference markers are clearly drafted to support technical interpretation.

The drawing further includes Footing Detail, indicating column base connections and foundation alignment to explain how loads are transferred from the superstructure to the ground. In addition, Section Plan CAD Blocks & DWG Drawing Models are visible through sectional representations that explain floor levels, slab thickness, staircase continuity, and internal height relationships. Level markers and sectional cuts help in understanding vertical coordination across the building. All elements are drafted with clean CAD line work, readable annotations, and accurate proportions, making this AutoCAD DWG file useful for understanding column placement, beam alignment, footing reference, and section-based coordination for building construction drawings.
