15x16m first floor school plan of pipeline detail drawing
Description
15x16m first floor school plan of pipeline detail drawing is given in this AutoCAD model. The water line connections are given. Bath pipe, bidet, and basin diameter are 50mm. Water closet, FD, and Main pipe diameters are 100mm. The sink pipe dia is 80mm. For more details download the AutoCAD file.
