1200x200mm beam reinforcement is given in this model


Description

1200x200mm beam reinforcement is given in this model. The 25mm diameter is used the distance of 200mm. 11 numbers of bars are provided at the top section. 11 numbers of bars are provided at the bottom. For more details download the AutoCAD 2D drawing file.




File Type: DWG File ID: 188369

Uploaded by:


Meera
India
