500x350mm column cross section with 80mm distance of slab

500x350mm column cross section with 80mm distance of slab is given in this file. 20mm diameters of the 5 numbers of bars are provided at the top and bottom. Compacted backfill, polyethylene sheet, waterproofing membrane, 50mm blinding concrete and reinforcement details are provided. For more details download the AutoCAD 2D drawing file for free.
