800x900m steel plate connection drawing
Description
800x900m steel plate connection drawing is given in this AutoCAD file. Thickness of the stiffener is 16mm. The dimension of the steel plate is 800x900mm. Other details are given in this drawing model. For more details download the AutoCAD drawing file from our website.
