700mm length of the footing cum column section view
Description
700mm length of the footing cum column section view is given in this AutoCAD file. The length and breadth of the column is 500x400mm. The reinforcement details are given clearly. The total height of the footing is 0.5m. For more details download the AutoCAD drawing file from our website.
File Type:
DWG
File Size:
463 KB
Category::
Structure
Sub Category::
Section Plan CAD Blocks & DWG Drawing Models
