Description
A section view of the hanger drawing is given in this AutoCAD file. 10mm thickness of the guesst plate is provided. Trapeze type hanger and adjustable clevises hangers are provided. Support nut, and lock nuts are provided to hold the hanger form top. Material details are mentioned in this file. For more details download the AutoCAD drawing file from our cadbull website.
File Type:
DWG
File Size:
1.8 MB
Category::
Structure
Sub Category::
Section Plan CAD Blocks & DWG Drawing Models
type:
Gold
Tags
#A section view of the hanger drawing#Different kind of hanger drawing#adjustable clevises hangers#Trapeze type hanger
Uploaded by:
Pavithra
