A section view of the 36x11m ware house building


Description

A section view of the 36x11m ware house building is given in this CAD file. The front and left side of the sections are given. The total height of the warehouse building is 7.20m. A hall, terrace, counter, development economic space, preparation room, cleanliness room, room, and ware houses are available. For more details download the CAD file from our cadbull website.




File Type: DWG File ID: 191374

Uploaded by:


Meera
India
