25x50cm theme park column cross section with reinforcing detail drawing is given


Description

25x50cm theme park column cross section with reinforcing detail drawing is given. At the top, 5 bars are provided. At the bottom, 3 bars are provided. At the top, 8 numbers of 14mm diameter rod is provided. At the bottom, 8mm diameter with 100mm spacing is provided. For more details download the AutoCAD drawing file from our Cadbull website.
