Footing cum column vertical section drawing is given in this file. The total height of the column from ground level is 250cm. The dimension of the column is 15x30cm. Reinforcement details are mentioned in this drawing. At the bottom, river stone and sand levels are provided. For more details download the AutoCAD drawing file from our Cadbull website. For more details download the CAD file from our cadbull site. This can be used by architects and engineers. Download this 2d AutoCAD drawing file.
