Multifamily Wood Villa House Plan AutoCAD 2D Site Layout Drawing

This AutoCAD 2D drawing presents a detailed multifamily wood villa house plan prepared for residential master planning and architectural layout development. The drawing represents a duplex-style villa layout with clearly organized residential plots, internal roads, circulation networks, and housing clusters. The plan includes individual villa units designed with a living room, dining area, kitchen, common bathroom, and master bedroom with an attached toilet at ground floor level. Plot divisions, setbacks, road widths, parking arrangements, and open spaces are clearly shown to support accurate planning and coordination. The multifamily villa AutoCAD drawing, wood villa housing plan CAD, duplex villa layout AutoCAD, residential master plan CAD, villa housing layout drawing, and 2D residential site plan are drafted with precise line work and color-coded zoning.

The layout follows standard residential development planning principles, ensuring smooth vehicular circulation, efficient plot access, and balanced open space distribution. Internal road geometry, turning radii, service zones, and utility alignments are clearly indicated for execution level drawings. The wood villa configuration supports low-rise multifamily housing with organized community planning. Provided in AutoCAD-compatible DWG format, this drawing allows easy scaling, layer control, and modification. Architects, civil engineers, urban planners, interior designers, and CAD professionals can use the multifamily villa AutoCAD drawing, wood villa housing plan CAD, duplex villa layout AutoCAD, residential master plan CAD, villa housing layout drawing, and 2D residential site plan to save drafting time and maintain professional accuracy through a subscription download.
