The left side section view of the 10x22m house building


Description

The left side section view of the 10x22m house building is given in this file. This is G+ 1 house building. The garden, car parking, office room, living room, study room, kitchen, dining area, and outside sitting area are available on this ground floor. On this first floor, the living room, master bedroom with the attached toilet, two kid’s room, guest room, and common bathrooms are available. For more details download the AutoCAD drawing is given in this file.




File Type: DWG File ID: 193438
