Door Connection Detail With Plaster Panel Wall Section detail

This door connection detail drawing presents a construction section showing the installation of a door frame connected with a plaster panel wall system. The door connection detail illustrates how the door frame is fixed within the wall structure using support anchors and framing components. The drawing includes plan view, section view, and elevation showing the door opening dimensions and wall thickness used in the plaster panel wall assembly. Dimensional annotations indicate door height of 2.60 m and door width of approximately 0.90 m, along with wall panel thickness and installation clearances. The plaster panel wall system is shown with layered construction, including internal framing, wall panel surface, and finishing plaster layers that define the wall structure.
