The left side cut section view of the 25x10m residential 3bhk house building


Description

The left side cut section view of the 25x10m residential 3bhk house building is given in this model. The total height of the building up to roof level is 9.5m. This is G+ 1 house building. On this ground floor, the living room, kitchen, master bedroom with the attached toilet, dining area, and porch is available. On this first floor, the entrance area, kid’s room with the attached toilet, guest room with the attached toilet, bathtub, and balconies are available. For more details download the AutoCAD drawing model from our cadbull website.




File Type: DWG File ID: 250615
