This Architectural Drawing is Right and Left Elevation of house. An elevation drawing is an orthographic projection drawing that shows one side of the house. The purpose of an elevation drawing is to show the finished appearance of a given side of the house and furnish vertical height dimensions. Four elevations are customarily drawn, one for each side of the house. Elevations are typically created from the four main faces of the building: front, rear, right, and left. These views are typically named north, south, east, and west referring to the general direction the building faces. Architectural elevation drawings are useful for detailed renovations, such as in kitchen designs. Elevation plans enable you to view information that floor plans cannot convey, such as sizes of each drawer, cabinetry details, and each cabinet location. For more details and information Download the drawing file.
