Typical Plan of a Main Canal In Irrigation Project.

This Architectural Drawing is Typical Plan of a Main Canal In Irrigation Project. Main irrigation canal is the canal that delivers water to the lands to be irrigated and is composed of the off-load part (from the headword to the head of distribution canals) and working part where distributing conducting canals branch off from the main canal. Irrigation canal is an artificial channel that is the main waterway that brings irrigation water from a water source to the area to be irrigated. They can be lined with concrete, brick, stone or a flexible membrane to prevent seepage and erosion. For more details and information Download the drawing file.
