Section of Portal Area Tunnel in Canal.

This Architectural Drawing is Section of Portal Area Tunnel in Canal. There are three basic types of tunnel construction in common use. Cut-and-cover tunnels are constructed in a shallow trench and then covered over. Bored tunnels are constructed in situ, without removing the ground above. Finally, a tube can be sunk into a body of water, which is called an immersed tunnel. Long, prefabricated tube sections, made of steel or concrete and sealed to keep out water, are floated to the site and sunk in the prepared trench. Then divers connect the sections and remove the seals. Any excess water is pumped out, and the entire tunnel is covered with backfill. Tunnels have many uses: for mining ores, for transportation—including road vehicles, trains, subways, and canals—and for conducting water and sewage. For more details and information Download the drawing file.
