Cross section of irrigation project @7.05 with detailing

This architectural drawing is Cross section of lift irrigation project @7.15 with detailing.   In this section filling is 2.282, cutting is 78.717, and the datum is 199.0.  In this picture also given area report of the project.  In this drawing FF top level, HDR top level, design level, pre level, offset etc. are given with their details. For more details and information download the drawing file.
