Longitudinal section of main canal with plan and detailing

This architectural drawing is Longitudinal section of main canal with plan and detailing. This drawing includes data of cutting, filling, ground level, TBL, FSL, CBL, chainage etc. The longitudinal slope of a canal therefore is also known or is adopted with reference to the available country slope. However, the slope of canal bed would generally be constant along certain distances, whereas the local ground slope may not be the same. The alignment of a canal system depends on the topography of the land and other factors. For more details and information download the drawing file.
