This architectural drawing is AutoCAD 2d drawing of machine. It is pertaining to machine parts or components. It is presented through a number of orthographic views, so that the size and shape of the component is fully understood. Part drawings and assembly drawings belong to this classification. For more details and information download the dwg file.
