Top view of ramp with detailing

This architectural drawing is Top view of ramp with detailing. In this drawing there were total length of stair is 38700mm. If the slope of a ramp is between 1:12 and 1:16, the maximum rise shall be 30 inches (760 mm) and the maximum horizontal run shall be 30 feet (9 m). If the slope of the ramp is between 1:16 and 1:20, the maximum rise shall be 30 inches (760 mm) and the maximum horizontal run shall be 40 feet (12 m). For more details and information download the drawing file.
