Cross section of balcony with reinforcement details

This architectural drawing is Cross section of balcony with reinforcement details. The balcony structure is supported using vertical pillars or posts. The weight of the balcony or balconies (if stacked on top of each other) is supported by these pillars and transferred to the ground where concrete pads are usually cast. In this drawing there were given balcony section with notations and their dimensions. For more details and information download the drawing file.
