Column and jamb details of balcony

This architectural drawing is Column and jamb details of balcony. Steel planks extend from the building's frame and are then filled with concrete. On both types of balconies, railings are added after initial construction and are either embedded into the concrete of the balcony or surface mounted. In this drawing there were given slab thickness, height of column, total length etc. included. For more details and information download the drawing file.
