This Architectural Drawing is AutoCAD 2d drawing of Foundation Detail of stub column. A stub column is a type of column whose length is short and baseless which means do not have a foundation and footing as its rests on a beam or slab. It acts as a point load on the beam. A stub column does not fail by buckling because of its short length and It is constructed between one floor only. The purpose of stub column is providing to increase stiffness( the rigidity of a structural element that is able to resist deformation under the action of an applied force). A stub column is used to transfer load one from another beam. For more details and information download the drawing file.
