Reinforcement detail drawing of lean concrete.


This Architectural Drawing is AutoCAD 2d drawing of Reinforcement detail drawing of lean concrete. Reinforcement drawing – A reinforcement drawing shows the positions of all reinforcing elements in a particular structure or a structural element. Details drawing – Structural details are included in a separate drawing or in an original drawing as a special information (always in proper scale). Structural reinforcement is typically placed in the bottom portion of the slab thickness to increase the slab's load capacity. Most structural slabs-on-ground have both top and bottom layers of reinforcement for controlling crack-widths and increasing load capacities. For more details and information download the drawing file.
