Wall Construction Detal


Description

Wall Construction Detal dwg file.The sidewalks are emptied in suitable sizes and in a ramped form, reaching differences of max. 0.4 m. between cloths. the curve length of the wall located between ramps at the corners and indicated on the floor plans (sidewalks and track signs).   "H" is the variable height of the wall, having as its starting and ending levels the respective ramps of each corner less thickness of 10 cm.
