Window section with detailing

This architectural drawing is Window section with detailing. It is comprised of the head, jamb and sill. The head is the main horizontal part forming the top of the window frame. Jambs are the main vertical parts forming the sides of a window frame. A sill is the main horizontal part forming the bottom of the frame of a window. In Drawing there were given 195x146mm. For more details and information download the drawing file.
