Back sectional elevation of a university.


Description

This Architectural drawing is AutoCAD 2d drawing of Back sectional elevation of a university. A section shows only the information contained on the cut line. A section elevation shows not only this information but also details behind the cut line, including plants, buildings and other elements. A sectional view represents the part of an object remaining after a portion is assumed to have been cut and removed. The exposed cut surface is then indicated by section lines. Hidden features behind the cutting plane are omitted, unless required for dimensioning or for definition of the part. For more details and information download the drawing file.




File Type: DWG File ID: 255508
