Front and side elevational section with detail dimensions.


Description

This Architectural Drawing is AutoCAD 2d drawing of Front and side elevational section with detail dimensions. An Elevation drawing is drawn on a vertical plane showing a vertical depiction. A section drawing is also a vertical depiction, but one that cuts through space to show what lies within. An elevation drawing is an orthographic projection drawing that shows one side of the house. The purpose of an elevation drawing is to show the finished appearance of a given side of the house and furnish vertical height dimensions. Four elevations are customarily drawn, one for each side of the house. For more details and information download the drawing file.




File Type: DWG File ID: 255608

Uploaded by:


Presenting the broken author avatar :D Eiz Luna
New-Zealand
