18x11m house plan water pipe line valve connections
Description
18x11m house plan water pipe line valve connections are given. Hot water column, PVC pipe byepass valve, potable water, cold water column, sink line, shower line, toilet line, bath tub line, laundry line, washing machine, floor drain, discharge line, and electrical heater lines are provided.
