Typical Concrete intermediate space details in AutoCAD, dwg file.

This Architectural Drawing is AutoCAD 2d drawing of Typical Concrete intermediate space details in AutoCAD, dwg file. The following recommended tips should be observed: Maximum joint spacing should be 24 to 36 times the thickness of the slab. Joints should be spaced about 10 feet and a maximum of 15 feet. When using joint groove for contraction joints, the joint should be a minimum depth of 1/4 thickness of the slab.
