General mesh details in section in AutoCAD, dwg file.

This Architectural Drawing is AutoCAD 2d drawing of General mesh details in section in AutoCAD, dwg file. Using wire mesh is a common method to reinforce poured concrete. The wire mesh makes a square grid pattern which is laid down before the concrete gets poured. The wire mesh is usually one layer of a two-dimensional grid that runs along the length and width of the poured concrete, but not the height.
