This Architectural Drawing is AutoCAD 2d drawing of Machinery equipment installation details in AutoCAD, dwg file. Equipment Installation means any actions that are necessary to attach the equipment to the building including, but not limited to bolting or welding. A proper installation has many steps, and each one must be followed if the equipment is to work right. Poorly installed equipment can also be a safety hazard for employees and void product warranties. If your loading dock equipment is installed correctly, it will last for years.
