Framework of pillar and beam in AutoCAD, dwg file.

This Architectural Drawing is AutoCAD 2d drawing of Framework of pillar and beam in AutoCAD, dwg file. The beam of this connection rests on a cantilever of the column by the means of a circular bar welded on the bottom flange of the beam. The top flange is connected to one end of a dissipative plate which on the other end is attached to the column flange.
