Cross section A of the structure and column and sloof section details in AutoCAD 2D drawing, CAD file, dwg file
Description
Cross section A of the structure and column and sloof section details in AutoCAD 2D drawing. 70x70 sized column section and 30x40cm sized sloof section with reinforcement details in this drawing. slab reinforcement details are also given in this drawing. For more detailed information visit our pages and Download the 2D Autocad DWG file.
File Type:
DWG
File Size:
1.6 MB
Category::
Construction
Sub Category::
Concrete And Reinforced Concrete Details
