Wall Footing Design Sections WF1 WF2 With Foundation Base Detail

Wall footing design sections WF1 WF2 with foundation base detail drawing presents structural footing construction used for supporting masonry walls in building foundations. The drawing illustrates two footing section types labeled WF1 and WF2, which demonstrate the arrangement of the foundation base and wall connection above the footing. Each section clearly shows the masonry wall positioned centrally above the footing block, which distributes structural loads into the foundation base. The detail includes footing base alignment with compact soil level and foundation depth used for structural stability. Section references explain the connection between wall structure and footing base, including foundation wall placement and support base layer used to resist building loads transferred from the wall.
