AutoCAD Master Plan of NSG Regional Hub with Road and Layout Details

This AutoCAD Master Plan drawing illustrates the complete NSG Regional Hub at Lekhawada, Gandhinagar, Gujarat, designed under CPWD guidelines. It includes detailed layouts for administrative, residential, training, and service infrastructure, including roads (6m, 9m, 12m, and 18m widths), parking areas, and stormwater drainage systems. The drawing outlines Type-II (104 units), Type-III (40 units), Type-IV (14 units), and Type-V (2 units) quarters, along with the Administrative Building, Lecture Hall, Officer’s Mess, MI Room, AC Mess, 280-Men CDO Barrack, and STP with UG sump and pump rooms.

It follows the C.G.D.C.R.-2017 norms, ensuring compliance with building height (max. 44.55m), fire safety, solar provisions, drainage, and rainwater harvesting. Additional provisions include footpaths, culverts, retaining walls, electrical substations, and green landscape areas with tree plantation zones.

Perfect for professionals in road design, AutoCAD drawing, typical road design, road cross section, AutoCAD road section drawing, and urban road construction design for EPC and civil infrastructure projects.
