High Rise Public Housing Elevation Plan With Sky Terrace Levels DWG

This AutoCAD DWG architectural elevation drawing represents a 47-storey public housing residential building designed under the Kallang Whampoa Contract 36 project for Singapore’s Housing & Development Board (HDB). The elevation showcases detailed floor levels from 1st to 47th storey, including sky terrace levels on the 22nd and 34th floors, main roof (142.625 m), upper roof (149.675 m), and water tank level (144.925 m).

The design includes 1.25m high balcony railings, 15mm groove line gaps at window panels, and 2.3m RC parapet walls, ensuring both safety and ventilation. The building’s vertical dimensions are precisely annotated, ranging from ground level (4.1 m) to upper roof (150.500 m), offering clear construction guidance for architects and engineers.

Developed by JGP Architecture (S) Pte Ltd, this elevation also includes detailed structural coordination notes, window alignment specifications, and contractor verification guidelines. Ideal for architects, civil engineers, and builders, this DWG drawing serves as a reference for high-rise public housing design and elevation detailing.
