High Rise Studio Apartment Floor Plan With Balcony and Kitchenette

This AutoCAD DWG high-rise studio apartment floor plan showcases a well-organised layout designed for modern urban living. The plan includes bedrooms, living/dining areas, kitchenettes, bathrooms, and laundry spaces, each defined with clear sill levels (+4.575m) and lintel levels (+6.663m) for precise elevation control.

Each studio unit features a balcony (2450 mm), bathroom (1800 mm), and kitchen (1300–1400 mm), along with living/dining zones averaging 2800 mm in length. The concrete platforms (100 mm height) are finished with tile skirting, ensuring easy maintenance and refined detailing. Decorative columns, OTS ventilation shafts, and combo roofing systems add architectural depth and ventilation efficiency.

Ideal for architects, civil engineers, and interior designers, this plan offers a versatile apartment design suitable for high-rise residential projects and mixed-use developments.
