Typical Apartment Floor Plan with 1BHK Units Living Dining and Kitchen

This AutoCAD DWG typical floor plan represents a residential apartment layout repeated from the 1st to 12th floor. Each unit includes a Living Room (10'-0" x 15'-10" or 9'-0" x 15'-2"), Dining Area (4'-6" x 8'-0"), Master Bedroom (10'-0" x 11'-0"), Bedroom (9'-2" x 10'-0" / 9'-0" x 11'-0"), and Kids Room (7'-0" x 7'-0") depending on the unit type. Kitchens range from 7'-0" x 11'-0" to 10'-0" x 7'-0" with attached Toilets (7'-4" x 4'-6" / 6'-0" x 4'-0"). Vertical circulation includes two Lifts (9'-0" x 6'-0"), a Fire Lift (6'-0" x 5'-0"), and Staircases connected to 7'-8" x 10'-0" lobby spaces. Corridors have 4'-0" wide passages for common movement. Saleable areas vary between 870 sq ft and 1150 sq ft, making the plan suitable for compact apartment developments.
