Multi Unit Apartment Floor Plan with 1BHK and 2BHK Flats Layout DWG

This AutoCAD DWG apartment floor plan shows multiple 1BHK and 2BHK units arranged around a central Lobby with Lifts, Stretcher Lift, Fire Lift, and Staircase Cores.

1BHK units generally include a Living Room (9'-0" x 13'-3" to 15'-3"), Kitchen (7'-0" x 9'-6" / 6'-0" x 10'-0"), Bedroom (9'-0" x 10'-0"), and Attached Toilet (7'-0" x 4'-0") with Dry Balcony (3'3" wide).

2BHK units feature a Living Room (19'-0" x 9'-0" / 10'-0" x 21'-0"), Dining Space (up to 13'-3" x 3'-0"), Kitchen (10'-0" x 7'-0"), Master Bedroom (10'-0" x 9'-0"), Secondary Bedroom (11'-0" x 9'-0"), and Toilets (7'-0" x 4'-0" / 4'-0" x 7'-0"), with Balconies (4' to 5' wide) for ventilation.

The design includes 5’ wide common passages, chajjas, service shafts, and fire lobby zones, making this layout suitable for residential building design and approval documentation.
