Mercedes Urban Bus AutoCAD DWG Design with Seating Layout Plan

This AutoCAD DWG file features a detailed Mercedes urban bus design, showcasing comprehensive seat distribution, body dimensions, and technical views. The layout includes Mercedes OF1417 and OH1418 bus models, with seating capacities of 35+1 and 44+1 passengers, designed for urban passenger transport and vehicle body fabrication projects.

The 1:50 scale drawings present side, front, and rear elevations, floor plans, and sectional cut views highlighting emergency exits, interior fittings, and ergonomic seating arrangements. Key details include total weight capacity of 16800 kg, passenger load tolerance of ±5%, and wheelbase dimensions of 5250 mm. The plan also features polypropylene and upholstered seat variants, along with lighting, mirrors, and structural details that meet professional automotive drafting standards.

Key Highlights:

• Authentic Mercedes bus models (OF1417 and OH1418) with technical accuracy.
• Detailed seat plan, including driver, passenger, and accessibility zones.
• Includes engineering tolerances, weight data, and sectional specifications.
• Perfect for automotive engineers, industrial designers, and 3D modelers using AutoCAD, Revit, or SolidWorks.

This Mercedes bus AutoCAD DWG is ideal for those developing transportation systems, vehicle prototypes, or mechanical design studies.
