24x45 Residential House CAD Plan with Elevation and RCC Details

1. Building Type:

This AutoCAD file represents a G+2 residential house design featuring detailed architectural and structural components.

2. Plot Size & Dimensions:

The layout is designed for a 24’-0’’ x 45’-0’’ plot, providing efficient space utilization for urban residential planning.

3. Ground Floor Layout:

• Two shops measuring 9’-3’’ x 23’-0’’ each.
• T.V. Lounge sized 7’-9’’ x 16’-0’’.
• Bedroom of 10’-9’’ x 10’-0’’.
• Bathroom measuring 7’-9’’ x 4’-0’’.
• Passage 3’-6’’ wide with staircase access.
• Projection area: 2’-6’’ wide.

4. First & Second Floor Layout:

• Multiple bedrooms:
• 10’-9’’ x 12’-3’’
• 11’-9’’ x 11’-0’’
• 10’-9’’ x 15’-3’’
• Kitchen sized 4’-6’’ x 8’-6’’.
• T.V Lounge measuring 11’-9’’ x 12’-0’’.
• Bathrooms:
• 4’-9’’ x 4’-0’’
• 5’-9’’ x 4’-0’’
• 5’-3’’ x 4’-0’’
• Balcony with 4’-6’’ width.

5. Structural Section Details:

• RCC Slab: 5’’ thick.
• RCC Beams: 6’’ x 18’’.
• Plinth Beam: 9’’ x 18’’.
• Column Size: 6’’ x 18’’ with reinforcement schedule.
• Wall Section: 4 ½’’ thick with plinth beam detailing.

6. Area Schedule:

• Total Plot Area: 1080 sq ft.
• Open Area & Covered Area breakdown included.
• Ground Floor Covered: 971 sq ft.
• First Floor Covered: 971 sq ft.
• Total Built-up Area: 2913 sq ft.

7. Door & Window Schedule:

• Doors:
• D1: 3’-6’’ x 7’-0’’
• D2: 2’-6’’ x 7’-0’’
• Windows:
• W1: 4’-6’’ x 4’-0’’
• W2: 3’-0’’ x 4’-0’’
• W3: 2’-0’’ x 4’-0’’
• W4: 1’-6’’ x 4’-0’’
• Ventilators: 2’-0’’ x 1’-6’’.
• Gate: 4’-0’’ x 7’-0’’.

8. Additional Drawings Included:

• Front elevation with balcony and façade detailing.
• Section at X-Y showing slab heights, levels, and RCC distribution.
• Site Plan with north direction.
• Area Plan representing open and covered area markings.

9. Ideal For:

Architects, civil engineers, interior designers, and students need a complete residential CAD drawing with structural and dimension-accurate details.
