Sub Division AutoCAD Site Plan with Plot Dimensions and Floor Areas

This AutoCAD DWG subdivision site plan presents a complete layout of C.S.No 908 Part Plot No 134 and C.S.No 9557 Plot No 7, showcasing accurate measurements, plot boundaries, and possession details for each unit. The drawing includes lane and road widths, such as the 12 ft wide lane and 20 ft wide road, along with essential dimension markings like 16 ft 3 in, 14 ft 3 in, 21 ft, and 22 ft 3 in that define the structural spacing of the plots. Multiple floor plans are illustrated with scales of 32 ft 0 in equals 1 in, including first-floor, second-floor, and open roof divisions. The ground floor commercial staircase block measures 9 ft by 18 ft 8 in, accompanied by clearly listed flat areas such as 916 sq ft units and 1000 sq ft units for first-floor occupants.

The schedule of the area section further details property divisions, including 2000 sq ft open roof space and corresponding sq yd conversions for more precise calculations. Subdivision layouts also mark occupant names, street connections of 25 ft width, and the 40 ft plot lengths across multiple flat numbers. This detailed plan is ideal for architects, civil engineers, designers, and builders who require exact zoning references, unit-wise area breakdowns, and complete multi-floor site planning data before executing residential layout development.
