AutoCAD House Plan with Detailed Room Sizes and Car Porch Layout

This AutoCAD DWG house plan provides a detailed residential layout featuring accurately measured living spaces, circulation areas, and functional planning elements essential for architectural design. The ground-level layout includes a 16 ft by 14 ft TV lounge, a 15 ft by 14 ft master bedroom, and a 13 ft 6 in by 12 ft bedroom, all supported by well-defined bath spaces such as 10 ft by 4 ft 6 in and 6 ft 6 in by 8 ft. Additional key areas include a 10 ft 6 in by 11 ft kitchen, a 17 ft 6 in by 12 ft drawing room, and multiple open spaces measuring 5 ft by 5 ft, 10 ft by 3 ft 6 in, and 2 ft 6 in wide ventilation zones. The staircase blocks, detailed at 8 ft 6 in by 12 ft and 8 ft 6 in by 15 ft, provide central vertical movement, while the car porch layout measuring 12 ft by 18 ft ensures smooth vehicular access.

The upper-level layout expands functionality with a spacious 20 ft by 18 ft TV lounge, a 16 ft by 14 ft bedroom, a 12 ft by 16 ft bedroom, and multiple balcony projections set at 3 ft 6 in wide, supporting enhanced ventilation and circulation throughout the home. Additional elements include a 10 ft by 11 ft courtyard, an 8 ft 6 in by 5 ft lobby, and a secondary 16 ft by 24 ft car porch for an extended parking space. Every area in this DWG file is marked with accurate dimensions, making it highly valuable for architects, civil engineers, interior designers, and builders who require precise residential planning data before beginning design or construction.
